A4J500
$8.41
Amp-Trap fast-acting A4J fuses deliver excellent current-limiting protection to a wide variety of applications. Their unique dimensions prevent the substitution of other fuses with lower voltage ratings, interrupting ratings, or current-limiting capability.
Specifications
| Item number | A4J500 |
| Description | Fuse A4J – Class J – Fast-Acting 600VAC 300VDC 500A Blade Amp-Trap® |
| EAN/UPC Code | 782001960490 |
| Rated voltage AC UL | 600 V |
| Rated voltage DC UL | 300 V |
| Frequency (Hz) | 50/60 Hz |
| Ampere Rating | 500 A |
| AC or DC | AC/DC |
| Fuse Class | Class J |
| Speed/Characteristic | Fast-Acting |
| Mounting | Clip |
| AC Max I.R./Breaking Capacity: I1 | 200 kA |
| Connection/Terminal Material | Brass Alloy |
| Connection/Terminal Type | Blade |
| Product Diameter | 63.5 mm |
| Product Length | 203.2 mm |
| Sell Pack Quantity | 1 EA |
| Sell Pack Weight | 1.4379 kg |
| Sell Pack Width | 63.5 mm |
| Sell Pack Length | 222.2 mm |
| Sell Pack Height | 60.5 mm |
| Product group | Low Voltage UL/CSA Fuses |
| Body/Insulating Material | GMG |
| Product Weight | 1.3698 kg |
